Solax 8kW Three Phase Hybrid Inverter X3-HYBRID-8.0D

• 8kW nominal output power, with a peak of 18kW for 10 seconds
• 150% EPS overload output for improved backup performance
• Less than 10ms switchover time for continuous power supply
• Compatible with lithium-ion and lead-acid batteries
• Intelligent load management with heat pump support
• Parallel operation capability up to 150kW
• Five operation modes with two charging periods for flexibility
• Virtual Power Plant (VPP) ready for energy market participation
• Three-phase unbalanced output with a maximum of 5kW per phase
• Super-backup ready for EPS operation without batteries
• 200% PV oversizing and up to 110% AC overload output
• High charging and discharging efficiency of up to 97.5%
• Built-in shadow tracking function for enhanced solar output
• IP65 protection for durability in various weather conditions
• Compact and lightweight design (503 × 503 × 199 mm, 30 kg)
• Multiple communication interfaces, including RS485, WiFi, LAN, and USB
