Description

Solax 6kW Single Phase Hybrid Inverter X1-HYBRID-6.0D

• Assured Reliability

  • 150% EPS output for 10 seconds, handling peak load demand
  • UPS-level switching (<10ms) for smooth power transitions
  • IP65-certified, ensuring long-term durability

• High Performance

  • 200% PV oversizing and 110% AC output for higher efficiency
  • 97% charging/discharging efficiency for effective energy use
  • Low start-up voltage (90V) for extended operational hours

• Flexible Adaptability

  • Supports lithium-ion and lead-acid batteries
  • Max. 16A DC input current for high-efficiency panels
  • Parallel operation (up to 15kW) for grid and off-grid systems

• Smart Management

  • VPP readiness enables energy trading and grid participation
  • MPPT scan technology for optimized power harvesting
  • Smart load control for heat pumps and EV chargers
  • Fast load response (0.3s) with CT support

Specifications:

• Max. PV Array Power: 12.0 kWp
• Max. PV Input Voltage: 600V
• Rated Output Power: 6000W
• Weight: 24kg
